Anderson Plug Terminal Crimping Pliers

Anderson Plug Terminal Crimping Pliers

The quality Anderson plug terminal crimping pliers produced by Yueqing Woma Tools Co., Ltd can be used for 15, 30, and 45 amp power connectors. The AP-153045 crimping tool is designed for quick and effective connection of Anderson plug terminals. Our crimping tool has four advantages: it can crimp all three sizes of contacts, the built-in contact locator can fix the contact during the crimping process, the ratchet mechanism ensures correct crimping every time, and the ergonomic design can effectively reduce work fatigue. WOMA Tools sincerely looks forward to working with you!

Model:AP-153045

Send Inquiry

Product Description

WOMA Tools’s quality Anderson Plug Terminal Crimping Pliers are suitable for quick disconnect power connectors with 15, 30, and 45-ampere ratings. The tool features a built-in contact locator and ratchet mechanism to ensure correct crimping every time, and is rated for high current to safely handle higher loads or surges. It is suitable for quick disconnect power connectors used in VHF/UHF radios, automotive applications, two-way radios, audio equipment, fast-charging portable power stations, and robotics manufacturers.

WOMA Tools Anderson plug terminal crimping pliers has the following advantages:

● Purpose: The AP-153045 crimping tool is designed for crimping quick disconnect power terminal connectors, including 15/30/45AMP connectors and red/black battery connector modular power connectors.

● The high leverage crimping tool crimps 10-20 AWG power contacts with three crimping ports, where the 15AMP connector is suitable for 20-16 AWG wires, the 30AMP connector is suitable for 14-12 AWG wires, and the 45AMP connector is suitable for 10 AWG wires.

● Safe Connection: The crimping tool is equipped with a built-in contact locator to fix contacts during the crimping process, and a ratchet mechanism ensures that each crimp is correct. The ratchet release knob can be used to release any ongoing work at any time.

● High Rated Current: Qualified crimping with this tool can provide minimal contact resistance at high current, ensuring that the power connector can safely handle higher loads or surges.

● Applications: This tool is suitable for quick disconnect power connectors used in VHF/UHF radios, cars, two-way radios, audio equipment, fast charging portable power stations, and robot manufacturers.Specifications of our Anderson plug terminal crimping pliers


Specifications of our Anderson plug terminal crimping pliers

Model

Range of Application

Capacity

AWG

Length (mm)

Weight (kg)

AP-153045

For Anderson Powerpole Connector

15/30/45 mm2

16/18/20
12/14
10/12

250

0.55
